Measurement and Analysis of Turbodrill Blade Profile Based on Three Coordinate Measuring Machine
-
摘要: 涡轮钻具的核心部件为定转子，在定转子逆向工程研究和定转子精度检验中，均需测量定转子的叶片叶型。但是，目前还没有具有一定精度的相关测量方法。通过分析涡轮钻具定转子的结构特点，提出采用接触测量方式测量叶片叶型，以平均水力半径为切割路径去掉叶片叶冠而获得叶型，给出了测量叶型吸力面和压力面型线的方法。在获得测量数据点坐标的基础上，结合流体流动的要求，提出以点分组控制三次曲线的方法拟合被测叶片型线。利用该方法，测量了φ127.0 mm涡轮钻具某型转子的叶片叶型，获取了被测叶型上196点的坐标值，并根据测点坐标值计算得到了叶片型线。实例证明，提出的方法可行，精度基本可以达到要求，可为涡轮钻具定转子叶片的测量检验或逆向工程设计提供技术参考。Abstract: The core components of turbodrill are the stator and rotor.Profile measurement for rotor and stator blade is required in the study of the reverse engineering and accuracy test of the stator and rotor.This paper presents a method of contact measurement to measure blade profile through analyzing the structure characteristics of turbodrill’s stator and rotor,and the technique to obtain blade profile by using the mean hydraulic radius as the cutting path to cut off blade shroud,and gives the way to measure profile lines of the suction and pressure surfaces respectively.Based on the coordinates of measured points,an innovative method using the point packet controlling cubic curve manner to fit the blade profile under the fluid flow requirements is put forward.A type of φ127.0 mm turbodrill rotor blade profile was measured by this method,obtaining coordinate values of 196 points of measured blade profile,and based on the coordinates of measured points,blade profile lines were calculated.Case study shows the proposed method is feasible,it can meet the accuracy requirement,and provide technical references for measuring or reverse engineering design of turbodrill’s stator and rotor blades.
-
Keywords:
- turbodrill /
- blade /
- blade profile /
- measuring /
- curve fitting
-
-
[1] 许福东,张晓东.带同步减速器涡轮钻具工作力学与性能仿真[M].武汉:中国地质大学出版社,2004:2-5. Xu Fudong,Zhang Xiaodong.Working mechanics and performance simulation of turbodrill with synchronous reducer[M].Wuhan:China University of Geosciences Press,2004:2-5. [2] 李俊华.高速涡轮节设计与涡轮叶栅流场分析[D].成都:西南石油大学机电工程学院,2010. Li Junhua.Design of high-speed turbine section and flow field analysis of turbodrill blade[D].Chengdu:Southwest Petroleum University,School of Mechatronic Engineering,2010. [3] 万军,鞠鲁粤.逆向工程中数据点云精简方法研究[J].上海大学学报:自然科学版,2004,10(1):26-29. Wan Jun,Ju Luyue.Data reduction for reverse engineering[J].Journal of Shanghai University:Natural Science,2004,10(1):26-29. [4] 戴静.逆向工程数据处理关键技术研究[D].南京:南京理工大学机械工程学院,2003. Dai Jing.Key technology research of data processing in reverse engineering[D].Nanjing:Nanjing University of Science Technology,School of Mechatronic Engineering,2003. [5] Sobieczky H,Dulikravich G S,Dennis B H.Parameterized geometry formulation for inverse design and optimization:proceeding of 4th International Conference on Inverse Problems in Engineering,Angra dos Reis,Brasil,May 26-31,2002.
[6] 冯进,符达良.涡轮钻具涡轮叶片造型设计新方法[J].石油机械, 2000,28(11):9-12. Feng Jin,Fu Daliang.New design method of turbine blade shape of turbodrill[J].China Petroleum Machinery,2000,28(11):9-12. [7] 陈铁,刘仪,刘斌,等.轴流式叶轮机械叶型的参数设计方法[J].西安交通大学学报,1997,31(5):52-57. Chen Tie,Liu Yi,Liu Bin,et al.A character-parameter method for axial turbomachinery blade design[J].Journal of Xi’an Jiaotong University,1997,31(5):52-57. [8] 朱心雄.自由曲线曲面造型技术[M].北京:科学出版社,2000:32-42. Zhu Xinxiong.Freedom curve and surface modeling techniques[M].Beijing:Science Press,2000:32-42. [9] 白晓亮,张树生.涡轮叶片叶面B-spline曲面层次化拟合方法[J].航空学报, 2009,30(10):1978-1984. Bai Xiaoliang,Zhang Shusheng.Hierarchical B-spline surface fitting of turbine blades[J].Acta Aeronautica et Astronautica Sinica,2009,30(10):1978-1984. [10] Shahpar D S.A comparative study of optimization methods for aerodynamic design of turbomachinery blades[R].ASME 2000-GT-523,2000.
-
