The Technology of Integrated Layered Perforation and Formation Testing in One Trip
-
摘要: 为了实现一趟管柱对多个层位分别进行移位射孔、试油，或利用一趟管柱对同一层位进行二次射孔、试油，研究试验了一趟管柱分层射孔-试油联作技术。该技术的核心是在射孔管柱上加装泄压装置、两级减震装置，并将二级起爆装置的起爆方式由原来的常规投棒机械点火改变为投棒电起爆；同时，采用射孔管柱与APR全通径测试器串联并顺序下井的联作模式进行试油。将泄压装置和减震装置安装于射孔管柱，解决了射孔起爆时产生的高压和强烈震动对枪串二级起爆装置的冲击，电起爆的起爆形式使二次起爆更有保障。该联作技术在3口试验井进行了试验应用，施工均一次性成功，射孔发射率100%，试油结果与测井解释结果相符，油层投产顺利。现场试验表明，该技术简化了下井工具和井口装置，操作简便，可使井下作业及射孔成本降低27%；提高了分层测试的准确性，缩短了试油周期，试油成功率提高37%。Abstract: In order to achieve perforation and formation testing at in multiple layers,or to do perforation and formation testing at in the same layer twice in one trip run,a string combining layered perforation and formation testing functions has been developed.Its core idea is to add a pressure relief device,two levels of shock absorbing device to the conventional perforation string,and to change the secondary initiation method from conventional mechanical ignition to electric initiation.In addition,the combined operation mode with perforating string connected inseries and APR full size tester was adopted.The pressure relief device and shock absorbing device in perforating string has solved the problem perforation at the exit of detonation pressure and strong vibration impact to secondary blasting gun string device and electric initiationg ensures blast reliabilitying.The application of the combined string in 3 wells was successful,with perforating emission rate of 100%,and testing results were consistent with well logging interpretation,then reservoir was brought into production.The application showed this technology with simplified downhole tools and wellhead unit,could make field operation easier,and lower the cost of downhole operation and perforation by 27%;enhance the accuracy of layered formation test and shorten the testing cycle,and improve success rate of formation testing by 37%.
-
Keywords:
- pipe string /
- separate layer /
- perforation /
- oil production test /
- shock absorption
-
-
[1] 曾凡辉,尹建,郭建春.定向井压裂射孔方位优化[J].石油钻探技术,2012,40(6):74-78. Zeng Fanhui,Yin Jian,Guo Jianchun.Optimization of perforation orientation for directional well fracturing[J].Petroleum Drilling Techniques,2012,40(6):74-78. [2] 邓金根,蔚宝华,王金凤,等.定向射孔提高低渗透油藏水力压裂效率的模拟试验研究[J].石油钻探技术,2003,31(5): 14-16. Deng Jingen,Yu Baohua,Wang Jinfeng,et al.Simulation trial research on increasing hydraulic fracturing efficiency of low permeability reservoir by oriented perforation[J].Petroleum Drilling Techniques,2003,31(5):14-16. [3] 袁吉诚.中国射孔技术的现状与发展[J].测井技术,2002,26(5):421-425. Yuan Jicheng.On the development of perforating technology in China[J].Well Logging Technology,2002,26(5):421-425. [4] 刁刚田,刘志华,周家驹,等.复合射孔技术的应用[J].钻采工艺,2003,26(6):30-33. Diao Gangtian,Liu Zhihua,Zhou Jiaju,et al.The application of compound perforation technology[J].Drilling Production Technology,2003,26(6):30-33. [5] 郑志雄,毛志刚,李峰华,等.复合射孔技术的推广应用[J].油气井测试,2003,12(3):34-35. Zheng Zhixiong,Mao Zhigang,Li Fenghua,et al.The extend and its application of compound perforate technology[J].Well Testing,2003,12(3):34-35. [6] 姚志中,赵开良,焦建国,等.高温高压井射孔工艺技术在元坝X井的应用[J].测井技术,2013,37(1):114-117. Yao Zhizhong,Zhao Kailiang,Jiao Jianguo,et al.Application of perforating technique for high temperature and pressure well to Yuanba X Well[J].Well Logging Technology,2013,37(1):114-117. [7] 贺红民,路利军,慕光华,等.动力旋转定方位射孔工艺技术[J].测井技术,2013,37(4):451-454. He Hongmin,Lu Lijun,Mu Guanghua,et al.On dynamic rotary oriented perforation technology[J].Well Logging Technology,2013,37(4):451-454. [8] 刘河秀,郑长建,索明武.P-T仪的应用和发展[J].油气井测试,2002,11(4):69-70. Liu Hexiu,Zheng ChangJian,Suo Mingwu.Application and development of instrument P-T[J].Well Testing,2002,11(4): 69-70. [9] 逯启高.测试-射孔联作管柱优化[J].油气井测试,2007,16(1):50-51. Lu Qigao.Optimization of combined operation string of perforation and testing[J].Well Testing,2007,16(1):50-51. [10] 丁希杰,朱建新,杨华.投棒点火头安全设计及应用[J].石油仪器,2009,23(2):15-16. Ding Xijie,Zhu Jianxin,Yang Hua.Safety design of drop bar firing head and its application[J].Petroleum Instruments,2009,23(2):15-16. [11] 尹长城,王元勋.射孔测试联作减震器数值模拟及力学特性拟合[J].石油机械,2007,35(10):33-36. Yin Changcheng,Wang Yuanxun.Perforating testing associated shock absorber numerical simulation and mechanical properties fitting[J].China Petroleum Machinery,2007,35(10):33-36. [12] 张黎,朱全邦,孙建兵,等.测试射孔联作施工中常见的压力计及时钟故障分析[J].油气井测试,2003,12(6):61-62. Zhang Li,Zhu Quanbang,Sun Jianbing,et al.Fault analysis of familiar pressure gauge and clock in testing the construction with perforation[J].2003,12(6):61-62. -
