Laboratory Research on a New Styrene Acrylic Latex Cement Slurry System
-
摘要: 为提高苯丙胶乳的适用温度，满足高温固井的需求，以苯乙烯、丙烯酸丁酯、功能单体等为原料，合成了一种新型耐高温苯丙胶乳GR，并进行了500 kg的放大生产。室内评价了GR苯丙胶乳水泥浆体系的高温降滤失性、流变性、防气窜性能、稳定性和综合性能，对比了GR小样产品与中试产品的性能，论述了苯丙胶乳GR的作用机理。结果表明：GR苯丙胶乳水泥浆的滤失量可以控制在50 mL以下，耐温能力达到150 ℃；GR苯丙胶乳水泥浆具有良好的流变性、直角稠化、防气窜性能以及稳定性等特点，另外中试生产的苯丙胶乳的性能与室内小样产品均保持一致。综合分析认为，GR苯丙胶乳水泥浆可以满足150 ℃以下高温固井的要求。Abstract: In order to raise the applied temperature of the styrene acrylic latex and meet the needs of high-temperature cementing,a new high temperature resistant styrene acrylic latex GR was synthesized from styrene,butyl acrylate,and functional monomer,then 500 kg weight pilot product was produced.The properties(water-loss control property at high temperature,rheology,static gelling strength,stability,integrated engineering performances)of the cement slurry sample with styrene acrylic latex GR were evaluated then compared with that from pilot product.It shows that:fluid loss of the cement slurry with styrene acrylic latex GR can be controlled under 50 mL,while temperature tolerance is up to 150 ℃;It has good rheology,right-angle cementing,good anti-channeling performance and stability;and laboratory samples and pilot product have consistent performance.Comprehensive analysis shows that styrene acrylic latex GR can meet the requirements of cementing below 150 ℃.
-
-
[1] 齐奉忠,庄晓谦,唐纯静,等.国外新型水泥浆体系:胶乳水泥浆[J].石油钻探技术,2005,33(6):31. Qi Fengzhong,Zhuang Xiaoqian,Tang Chunjing,et al.Foreign new cement slurry:the cement slurry with latex[J].Petroleum Drilling Techniques,2005,33(6):31. [2] 马超,赵林,周大林,等.抗温防窜胶乳水泥浆体系的研制[J].天然气工业,2008,28(12):57-59. Ma Chao,Zhao Lin,Zhou Dalin,et al.Research on latex cement slurry system with heat-resisting and anti-channeling performance[J].Natural Gas Industry,2008,28(12):57-59. [3] 周仕明,李根生,方春飞.元坝地区146.1 mm尾管固井技术难点与对策[J].石油钻探技术,2010,38(4):41-44. Zhou Shiming,Li Gensheng,Fang Chunfei.Difficulties and countermeasures for 146.1 mm liner cementing in Yuanba Area[J].Petroleum Drilling Techniques,2010,38(4):41-44. [4] 瞿佳,严思明,许建华.胶乳防腐水泥浆在元坝地区的应用[J].石油钻探技术,2013,41(3):94-98. Qu Jia,Yan Siming,Xu Jianhua.Application of corrosion resistant latex cement slurry in Yuanba Area[J].Petroleum Drilling Techniques,2013,41(3):94-98. [5] 汪晓静,姚晓,阮玉媛.新型油井水泥低滤失高温缓凝剂的室内研究[J].钻井液与完井液,2007,24(2):48-49,52. Wang Xiaojing,Yao Xiao,Ruan Yuyuan.Laboratory research on low fluid loss high temperature retarder for oil well cementing[J].Drilling Fluid Completion Fluid,2007,24(2):48-49,52. [6] 丁岗,倪红坚,武红卫,等.胶乳对油井水泥浆作用机理的实验研究[J].石油大学学报:自然科学版,2001,25(2):16-18. Ding Gang,Ni Hongjian,Wu Hongwei,et al.Experimental study on action of latex on cement slurry of oil well[J].Journal of the University of Petroleum,China:Edition of Natural Science,2001,25(2):16-18. [7] 孔祥明,路振宝,张艳荣,等.有机助磨剂对水泥性能的影响及其有机水泥化学分析[J].硅酸盐学报,2012,40(1):49-55. Kong Xiangming,Lu Zhenbao,Zhang Yanrong,et al.Effect of organic grinding aids on cement properties and the analysis via organic cement chemistry[J].Journal of the Chinese Ceramic Society,2012,40(1):49-55. [8] Nelson E B.Well cementing[M].Amsterdam:Elsevier,1990:200-208.
[9] 张珍,杨远光,张杰,等.新型膨胀剂在胶乳水泥浆体系中的应用[J].石油钻探技术,2008,36(4):30-33. Zhang Zhen,Yang Yuanguang,Zhang Jie,et al.The development of new style expansion agent and its applications in latex cement system[J].Petroleum Drilling Techniques,2008,36(4):30-33. [10] 丁士东,周仕明,陈雷.川东北地区高温高压高含硫气井配套固井技术[J].天然气工业,2009,9(2):58-60,75. Ding Shidong,Zhou Shiming,Chen Lei.Cementing technology for "three highs" gas wells in Northeast Sichuan Basin[J].Natural Gas Industry,2009,29(2):58-60,75. -
期刊类型引用(9)
1. 李胜. 梨树断陷高温高压深定向井优快钻井技术. 西部探矿工程. 2023(05): 92-95+105 .
百度学术
2. 曾义金. 中国石化深层超深层油气井固井技术新进展与发展建议. 石油钻探技术. 2023(04): 66-73 . 本站查看
3. 路保平，丁士东，何龙，庞伟. 低渗透油气藏高效开发钻完井技术研究主要进展. 石油钻探技术. 2019(01): 1-7 . 本站查看
4. 陆沛青，桑来玉，谢少艾，高元，张佳滢，康旭亮. 苯丙胶乳水泥浆防气窜效果与失重规律分析. 石油钻探技术. 2019(01): 52-58 . 本站查看
5. 肖明明，郭锦棠，靳建洲，于永金，樊金杰. 油井水泥专用丁苯胶乳的实验评价. 化学工业与工程. 2017(06): 18-23 . 百度学术
6. 李早元，祁凌，刘锐，辜涛，孙劲飞. 空心微珠低密度水泥环完整性试验研究. 石油钻探技术. 2017(03): 42-47 . 本站查看
7. 张新贵，孔新民，王美洁，王容军，邓伟兵. 固井水泥浆胶乳的合成及性能评价. 长江大学学报(自科版). 2016(23): 49-53+6 . 百度学术
8. 齐奔，杜滨，高雪晴，于倩倩，刘文明，付家文，孙勤亮，林志辉. 油井水泥用胶乳的研究进展. 石油化工应用. 2016(06): 6-9 . 百度学术
9. 郭子涵，李明，杨燕，卢娅，郭小阳. 近年来油井水泥降失水剂研究现状概述. 现代化工. 2015(10): 49-53 . 百度学术
其他类型引用(10)
