Applications of Zwitterionic Polymer HRH Drilling Fluid in Linpan Oilfield
-
摘要: 临盘油田近些年油气井钻井多应用PAM钻井液，但该钻井液在使用中存在抑制能力不足、钻井液性能稳定时间短、防塌效果有限、使用成本较高等问题。为此，在借鉴国内外先进技术的基础上，引进了较为先进的两性离子聚合物HRH，通过溶解试验、絮凝试验、抑制性和配伍性试验对其进行了评价，优化了原有钻井液配方，研制出一种两性离子聚合物HRH钻井液。室内试验表明，该钻井液流变性能稳定，动塑比保持在0.5左右，耐温能力达150 ℃以上，抑制性优于PAM钻井液，其岩心渗透率恢复率高达90%以上，且与润滑剂复配后泥饼黏附系数小于0.1。在临盘油田295口井的现场应用表明，该钻井液的流变性、滤失性、润滑性和抑制性等均优于PAM钻井液，平均井径扩大率控制在10%以内，井下故障率由2.57%降至1.64%，平均机械钻速由20.58 m/h提高至23.02 m/h，具有良好的经济效益。由此可知，两性离子聚合物HRH钻井液能解决PAM钻井液所存在的问题，在临盘油田具有推广应用价值。Abstract: PAM drilling fluid has been commonly used in Linpan Oilfield in recent years,but this drilling fluid has shortcomings such as poor inhibition,short stable time,limited anti-sloughing property and higher cost,etc.In order to solve these problems,the advanced zwitterionic polymer HRH has been introduced based on the advanced techniques at home and abroad.The formula of the drilling fluid was optimized through solubility,flocculation,inhibition and compatibility test on HRH.The laboratory tests showed that the drilling fluid had good rheological property,with the ratio of yield value to plastic viscosity at around 0.5,temperature resistance of above 150 ℃,better inhibition than PAM drilling fluid,and the core permeability recovery rate of over 90%.When it was combined with lubricant,the mud cake adhesion coefficient could be lowered to less than 0.1.The HRH drilling fluid has been used in 295 wells in Linpan Oilfield,the results showed that the rheological property,filtration,lubrication and inhibition of the HRH drilling fluid were all better than that of PAM drilling fluid.After using the HRH drilling fluid,the average hole diameter enlargement ratio was kept under 10%,the downhole complex accidents was reduced from 2.57% to 1.64%,the penetration rate increased from 20.58 m/h to 23.02 m/h,which together resulted in good economic benefits.Thus it could be seen this drilling fluid which could solve all the problems of PAM drilling fluid,should be popularized in Linpan Oilfield.
-
Keywords:
- zwitterionic polymer /
- drilling fluid /
- laboratory test /
- field application /
- Linpan Oilfield
-
-
[1] 刘同富,王树永,李文明,等.胜利油田沙河街组及以下地层井壁稳定技术[J].钻井液与完井液,2003,20(5):64-65. Liu Tongfu,Wang Shuyong,Li Wenming,et al.Wellbore stabilization technology of the lower Shahejie Formation in Shengli Oilfield[J].Drilling Fluid Completion Fluid,2003,20(5): 64-65. [2] 王佩平,曹汉原,罗恒荣,等.一种多功能水基钻井液在临盘油田的应用[J].石油钻探技术,2007,35(3):49-52. Wang Peiping,Cao Hanyuan,Luo Hengrong,et al.The application of multifunctional water based drilling fluid in Linpan Oilfield[J].Petroleum Drilling Techniques,2007,35(3): 49-52. [3] 杨小华.钻井液用阳离子型和两性离子型聚合物处理剂的研究与应用[J].油田化学,1996,13(3):266-268. Yang Xiaohua.Cationic and amphoteric polymers as additives for drilling fluids:a review[J].Oilfield Chemistry,1996,13(3):266-268. [4] 曾李,于培志,任凌云,等.阳离子聚磺钻井液体系研究与应用[J].石油钻探技术,2009,37(6):61-66. Zeng Li,Yu Peizhi,Ren Lingyun,et al.Investigations and applications of cationic polysulfonate drilling fluid system[J].Petroleum Drilling Techniques,2009,37(6):61-66. [5] 范落成,杨兴福,王华,等.阳离子乳液聚合物钻井液在页岩气井的应用[J].石油钻探技术,2012,40(4):38-42. Fan Luocheng,Yang Xingfu,Wang Hua,et al.Application of cationic emulsion polymer drilling fluid in shale gas well[J].Petroleum Drilling Techniques,2012,40(4):38-42. [6] 刘锋,陈亮,厉磊.两性离子聚合物钻井液在陕北地区的应用[J].石油钻探技术,1998,26(4):22-23. Liu Feng,Chen Liang,Li Lei.Application of zwitterionic polymer drilling fluid in Shanbei Area[J].Petroleum Drilling Techniques,1998,26(4):22-23. [7] 刘平德,牛亚斌,张梅.两性离子聚合物钻井液体系PL的研制[J].天然气工业,2005,25(3):71-73. Liu Pingde,Niu Yabin,Zhang Mei.Development of zwitterionic polymer drilling fluid system PL[J].Natural Gas Industry,2005,25(3):71-73. [8] 王艾东,房延东,梁文斌,等.两性离子聚合物钻井液体系在桩139丛式井的应用[J].西部探矿工程,2006,18(12):111,114. Wang Aidong,Fang Yandong,Liang Wenbin,et al.Application of zwitterionic polymer drilling fluid system in cluster well of Zhuang 139 zone[J].West-China Exploration Engineering,2006,18(12):111,114. [9] 王学良,武永起,忽建泽,等.抑制性钾铵聚合物钻井液的推广应用[J].钻井液与完井液,2006,23(1):80-83. Wang Xueliang,Wu Yongqi,Hu Jianze,et al.Extended application of inhibitive potassium-ammonium polymer drilling fluid[J].Drilling Fluid Completion Fluid,2006,23(1):80-83. [10] 鄢捷年.钻井液工艺学[M].东营:石油大学出版社,2001: 199-206. Yan Jienian.Drilling fluid technology[M].Dongying:Petroleum University Press,2001:199-206. [11] 丁伟.丙烯酰胺类聚合物合成及性能研究[D].大庆:大庆石油学院石油工程学院,2006. Ding Wei.Studies on the synthesis and properties of acrylamide-based polymers[D].Daqing:Daqing Petroleum Institute,College of Petroleum Engineering,2006. [12] 王中华.国内钻井液及处理剂发展评述[J].中外能源,2013,18(10):34-43. Wang Zhonghua.The development overview on the domestic drilling fluids and drilling fluid additives[J].Sino-Global Energy,2013,18(10):34-43. [13] 钟汉毅,黄维安,林永学,等.新型聚胺页岩抑制剂性能评价[J].石油钻探技术,2011,39(6):44-48. Zhong Hanyi,Huang Weian,Lin Yongxue,et al.Properties evaluation of a novel polyamine shale inhibitor[J].Petroleum Drilling Techniques,2011,39(6):44-48. -
