A Method to Estimate Borehole Collapse Pressure Based on Shale Damage Law
-
摘要: 页岩的破坏有劈裂式、单剪切式、双剪切式等3种模式，而目前常用于预测井壁坍塌压力的Mohr-Coulomb准则仅适用于发生单剪切式破坏的井壁。针对该问题，首先基于最小耗散能原理和损伤力学，建立了包括页岩损伤演化方程、损伤阈值应变计算式、极限损伤变量计算式的页岩损伤力学模型；然后，以具有代表性的塔里木盆地群库恰克地区页岩地层标准岩心为研究对象，进行了常三轴抗压室内试验，并将试验得到的应力-应变曲线与理论曲线进行了对比分析，发现吻合较好；最后，将理论模型与室内试验结果相结合，研究了应变能密度与岩石破坏时应变、损伤阈值应变之间的关系曲线，并确定出维持井壁稳定的最低钻井液密度。分析认为，利用该种维持井壁稳定最低钻井液密度的确定方法，可以确定页岩地层的井壁坍塌压力。Abstract: Shale failure has three models:splitting,single shear and double shear,but Mohr-Coulomb criterion that commonly used in predicting borehole collapse pressure for shale formations at present is only suitable for the shale failure of single shear mode.In view of this issue,based on the principle of minimum energy and damage mechanics,the shale damage mechanics model including shale damage-evolution equation under confining pressure,damage-threshold strain formula and ultimate damage variable formula was established first;then conventional triaxial compression test was carried out with a typical shale core from Tarim basin,the comparison of stress-strain curve from testing and theoretical curve shows sufficient coincidence;at last,the relationship among strain energy density,strain and damage threshold strain was determined,and the minimum drilling fluid density to keep wellbore stable was established,by which the collapse pressure of shale can be calculated.
-
Keywords:
- rock mechanics /
- shale sloughing /
- mathematical model /
- stress /
- strain /
- hole stabilization
-
-
[1] 李庆辉,陈勉,金衍,等.页岩气储层岩石力学特性及脆性评价[J].石油钻探技术,2012,40(4):17-22. Li Qinghui,Chen Mian,Jin Yan,et al.Rock mechanical properties and brittleness evaluation of shale gas reservoir[J].Petroleum Drilling Techniques,2012,40(4):17-22. [2] 李庆辉,陈勉,金衍,等.页岩脆性的室内评价方法及改进[J].岩石力学与工程学报,2012,31(8):1680-1685. Li Qinghui,Chen Mian,Jin Yan,et al.Indoor evaluation method for shale brittleness and improvement[J].Chinese Journal of Rock Mechanics and Engineering,2012,31(8):1680-1685. [3] 高玮,汪磊,杨大勇.基于能量原理的岩石损伤研究[J].地下空间与工程学报,2010,6(增刊2):1672-1677. Gao Wei,Wang Lei,Yang Dayong.Study on the rock damage evolution based on energy principle[J].Chinese Journal of Underground Space and Engineering,2010,6(supplement 2): 1672-1677. [4] 张行.断裂与损伤力学[M].北京:北京航空航天大学出版社,2009:318-360. Zhang Xing.Fracture and damage mechanics[M].Beijing:Beijing University of Aeronautics and Astronautics Press,2009:318-360. [5] 高玮,汪磊,杨大勇.岩石损伤演化的能量方法研究[J].岩石力学与工程学报,2011,30(增刊2):4087-4092. Gao Wei,Wang Lei,Yang Dayong.Rock damage evolution based on energy principle[J].Chinese Journal of Rock Mechanics and Engineering,2011,30(supplement 2):4087-4092. [6] 谢水祥,蒋官澄,陈勉,等.破解塔里木盆地群库恰克地区井壁失稳难题的钻井液技术[J].天然气工业,2011,31(10):68-72. Xie Shuixiang,Jiang Guancheng,Chen Mian,et al.Drilling fluid technology in preventing the wellbore instability in the Qunkuqiake Area,Tarim Basin[J].Natural Gas Industry,2011,31(10):68-72. [7] 杨桂通.弹塑性力学引论[M].北京:清华大学出版社,2004:49-52. Yang Guitong.Introduction to elasticity and plasticity[M].Beijing:Tsinghua University Press,2004:49-52. [8] 金衍,陈勉.井壁稳定力学[M].北京:科学出版社,2012: 21-35. Jin Yan,Chen Mian.Wellbore stability mechanics[M].Beijing:Science Press,2012:21-35. [9] 陈勉,金衍,张广清.石油工程岩石力学[M].北京:科学出版社,2008:57-66. Chen Mian,Jin Yan,Zhang Guangqing.Rock mechanics related to petroleum engineering[M].Beijing:Science Press,2008: 57-66. -
