Understandings on Drilling Technology for Long Horizontal Section Wells
-
摘要: 为进一步明晰长水平段水平井与大位移井及常规水平井的差异，探讨相关钻井技术发展思路，进行了长水平段水平井技术特性分析。经分析、对比，认为三者之间的主要区别为：长水平段水平井重点解决的摩阻扭矩问题在常规水平井中不突出；其主要技术目标和形态特征是“相对较长”的水平段，但很多情况下不属于大位移井定义的范畴；相关钻井技术主要关注井斜角为86°以上“长”井段的作业能力，有别于大位移井以水平位移为目标的钻井完井能力。基于上述认识，提出了可表征长水平段水平井形态特征的初步定义，并从完善钻井设计基础理论、创新长水平段提速工艺和经济钻进模式等方面给出了详细建议。Abstract: In order to further clarify the differences among long horizontal section wells,extended reach wells and conventional horizontal wells,and explore drilling technologies and relative developing strategy for long horizontal section wells,the technical characteristics of these kinds of wells were analyzed.The analysis and comparison shows the main differences among the three kinds of wells are as follows:the problem of drag and torque in long horizontal section wells is not serious in conventional horizontal wells;long horizontal section wells feature a long horizontal section,which is beyond the range of extended reach well in many cases;the relative technologies have been focused on the drilling ability for the long horizontal section with deviation of more than 86°,it is different from the drilling and completion capability in extended reach wells that aimed at getting a long displacement.Based on the findings above,preliminary definition of long horizontal section wells was presented,and some specific suggestions on basic drilling design theory,drilling technology for improving ROP of long horizontal section and economic drilling model have been proposed.
-
-
[1] 郭元恒,何世明,刘忠飞,等.长水平段水平井钻井技术难点分析及对策[J].石油钻采工艺,2013,35(1):14-18. Guo Yuanheng,He Shiming,Liu Zhongfei,et al.Difficulties and countermeasures for drilling long lateral-section horizontal wells[J].Oil Drilling Production Technology,2013,35(1):14-18. [2] 何龙,李文生,刘伟.川西地区长水平段水平井钻井技术[J].钻采工艺,2013,36(5):114-116. He Long,Li Wensheng,Liu Wei.Drilling technology for long horizontal section wells in Western Sichuan[J].Drilling Production Technology,2013,36(5):114-116. [3] 赵恒,罗勇,赵金丰,等.苏里格气田长水平段水平井快速钻井技术[J].钻采工艺,2012,35(6):108-109. Zhao Heng,Luo Yong,Zhao Jinfeng,et al.Fast drilling technology or long horizontal section wells in Sulige Gas Field[J].Drilling Production Technology,2012,35(6):108-109. [4] 陈作,何青,王宝峰,等.大牛地气田长水平段水平井分段压裂优化设计技术[J].石油钻探技术,2013,41(6):82-85. Chen Zuo,He Qing,Wang Baofeng,et al.Design optimization of staged fracturing for long lateral well in Daniudi Gas Field[J].Petroleum Drilling Techniques,2013,41(6):82-85. [5] 韩来聚,牛洪波,窦玉玲.胜利低渗油田长水平段水平井钻井关键技术[J].石油钻探技术,2012,40(3):7-11. Han Laiju,Niu Hongbo,Dou Yuling.Key drilling technologies for long displacement horizontal wells of low permeability reservoirs in Shengli Oilfield[J].Petroleum Drilling Techniques,2012,40(3):7-11. [6] 赵金洲,韩来聚,唐志军.高平1井大位移水平井钻井设计与施工[J].石油钻探技术,2010,38(6):29-32. Zhao Jinzhou,Han Laiju,Tang Zhijun.Design and drilling of Gaoping 1 ERD horizontal well[J].Petroleum Drilling Techniques,2010,38(6):29-32. [7] 冯光通,马凤清,曹向峰,等.高平1井井眼轨道与井身结构设计[J].石油钻探技术,2010,38(6):33-36. Feng Guangtong,Ma Fengqing,Cao Xiangfeng,et al.The trajectory and casing program design of Well Gaoping 1[J].Petroleum Drilling Techniques,2010,38(6):33-36. [8] 牛洪波.大牛地气田长水平段井眼轨迹控制方法[J].天然气工业,2011,31(10):64-67. Niu Hongbo.Trajectory control methods for long sections of horizontal wells at the Daniudi Gas Field[J].Natural Gas Industry,2011,31(10):64-67. [9] GB/T 28911—2012 石油天然气钻井工程术语[S]. GB/T 28911—2012 Vocabulary of drilling engineering for petroleum and natural gas[S]. [10] 李克向,周煜辉,苏义脑,等.国外大位移井钻井技术[M].北京:石油工业出版社,1998:1-2. Li Kexiang,Zhou Yuhui,Su Yinao,et al.Foreign extended well drilling technology[M].Beijing:Petroleum Industry Press,1998:1-2. [11] 苏义脑,窦修荣.大位移井钻井概况、工艺难点和对工具仪器的要求[J].石油钻采工艺,2003,25(1):6-10. Su Yinao,Dou Xiurong.General condition and technical difficulties of extended reach drilling and its requirements on tools and instrument[J].Oil Drilling Production Technology,2003,25(1):6-10. [12] 周延军,曾强渗, 窦玉玲,等.金平1浅层大位移水平井钻井工程设计技术及应用[J].钻采工艺,2008,31(增刊1): 24-27. Zhou Yanjun,Zeng Qiangshen,Dou Yuling,et al.Drilling design and application for shallow extended reach horizontal well in Jinping Well 1[J].Drilling Production Technology,2008,31(supplement 1):24-27. [13] 李淑森,王霞,高含.苏里格气田水平井钻井提速技术分析与对策[J].钻采工艺,2012,35(5):115-117. Li Shusen,Wang Xia,Gao Han.Technical difficulties and measures of improving ROP of horizontal wells in Sulige Gas Field[J].Drilling Production Technology,2012,35(5): 115-117. [14] 谯抗逆,郭世侯,吴凯彬,等.长水平段地质导向技术在磨030-H24井中的应用[J].钻采工艺,2012,35(2):94-96. Qiao Kangni,Guo Shihou,Wu Kaibin,et al.Application of geosteering drilling technology in the long horizontal section of Well Mo 030-H24[J].Drilling Production Technology,2012,35(2):94-96. [15] 韩来聚,周延军,唐志军.胜利油田非常规油气优快钻井技术[J].石油钻采工艺,2012,34(3):11-15. Han Laiju,Zhou Yanjun,Tang Zhijun.High quality and fast drilling techniques for unconventional oil and gas reservoirs in Shengli Oilfield[J].Oil Drilling Production Technology,2012,34(3):11-15. [16] Colin Gillan,Scott Boone,Greg Kostiuk[R].Applying precision drill pipe rotation and oscillation to slide drilling problems.SPE 118656,2009.
-
期刊类型引用(16)
1. 于洋，谢南星，孙风景. 川西地区超高压气井井下节流设计及投产技术. 天然气勘探与开发. 2024(01): 46-54 .
百度学术
2. 侯冬青，刘小岑，郑伟涛，赵彬，姜许健，林清金，王俊芳，姚杰，旷曦域. 塔里木盆地东河1油田石炭系油藏注气开发气油比上升问题及对策. 大庆石油地质与开发. 2022(02): 51-58 . 百度学术
3. 罗睿乔. 井下节流技术在南海东部高温气田的应用. 海洋工程装备与技术. 2022(01): 58-66 . 百度学术
4. 文宏武，杜成刚，康凯，杨先辉，冀海洋，刘洪伟. 超高压气井地面计量热交换及控制系统. 油气井测试. 2022(06): 17-21 . 百度学术
5. 于洋，王威林，彭杨，谭昊，董宗豪，周玮. 超高压气井井下节流技术应用和设计方法. 天然气与石油. 2020(06): 80-85 . 百度学术
6. 王发清，曹建洪，曹献平，任利华，兰美丽，周行文. 注烃气驱受效井井下节流工艺设计方法与应用. 西部探矿工程. 2019(03): 76-79 . 百度学术
7. 易俊，张宝，薛旭周，王宏亮，李娇龙，张少阳. 高温高压凝析气井井下节流工艺优化设计. 长江大学学报(自然科学版). 2019(07): 45-49+3 . 百度学术
8. 原飞. 低温气井井口水合物防止工艺探讨. 化学工程与装备. 2018(07): 60-61 . 百度学术
9. 郭宏勃，陈晓东，于苏浩，张锐. 气井井下节流器的工艺技术探讨. 石化技术. 2018(04): 82 . 百度学术
10. 徐建宁，郑舜泽，李中文，席文奎，卫亚明，杨旭东. 接箍锚定式井下节流器锚定机构性能分析及优化. 石油钻探技术. 2018(02): 103-108 . 本站查看
11. 李会会，周生福，刘练，樊凌云. 塔河油田试井作业遇阻卡原因及防治措施. 油气井测试. 2018(05): 66-72 . 百度学术
12. 苗典远，孙长利，初德军，刘英伟，李允智. 高温高压钻井技术的探索与认识. 海洋石油. 2017(01): 85-89 . 百度学术
13. 卢智慧，何雪芹，刘志恒，钟敏. 考虑环境因素的井筒流动温度场计算. 断块油气田. 2016(05): 652-654 . 百度学术
14. 安永生，曹孟京，兰义飞，高月. 井下节流气井的生产动态模拟新方法. 天然气工业. 2016(04): 55-59 . 百度学术
15. 胡飚，朱宏武，孔祥领，张悠江，徐芳玲，吕慧琴. 水下采油树节流阀中天然气水合物生成分析. 石油机械. 2015(10): 42-46 . 百度学术
16. 孙小辉，孙宝江，王志远，王金堂. 超临界CO_2钻井井筒水合物形成区域预测. 石油钻探技术. 2015(06): 13-19 . 本站查看
其他类型引用(6)
