新型钻井液成膜剂的研制及其在埕海油田的应用

张朔; 蒋官澄; 郭海涛; 汤新国; 金海锋

doi:10.3969/j.issn.1001-0890.2013.02.009

新型钻井液成膜剂的研制及其在埕海油田的应用

1.
中国石油大学(北京)石油工程学院, 北京 102249;
2.
中国石油大港油田分公司, 天津 300289

详细信息

作者简介:
张朔(1986-),男,安徽阜阳人,2007年毕业于中国石油大学(华东)信息与计算科学专业,2011年获常州大学化工过程机械专业硕士学位,在读博士研究生,主要从事油气层损害与保护、油田化学等方面的研究工作。联系方式zhangshuo915@sina.com。

中图分类号: TE254.⁺4
计量
- 文章访问数: 3228
- HTML全文浏览量: 74
- PDF下载量: 3856
出版历程
- 收稿日期: 2012-10-08
- 修回日期: 2013-01-23
- 刊出日期: 2013-04-18

Development of New Film-Forming Agent for Drilling Fluids and Application in Chenghai Oilfield

1.
Petroleum Engineering College, China University of Petroleum, Beijing, 102249, China;
2.
Dagang Oilfield Branch of CNPC, Tianjin, 300289, China

摘要

摘要: 为了降低埕海油田钻井过程中外来流体对储层的损害,基于成膜钻井液技术的基本理论,以苯乙烯、丙烯酸丁酯单体为原料,采用乳液聚合的方法,以过硫酸铵为引发剂,合成了新型钻井液成膜剂LCM-8。室内试验表明:埕海油田上部钻井液中加入成膜剂LCM-8后,流变性能能够满足携岩要求;能在岩心污染端形成一个渗透率极低的封堵带,封堵率可达90%以上;返排渗透率恢复率大于90%。新型钻井液成膜剂LCM-8在埕海油田2口井的储层钻进过程中进行了应用,结果表明,上部钻井液加入该成膜剂后,其性能能满足钻井要求,2口井的表皮系数为-2.31和-3.11,而未用该成膜剂2口邻井的表皮系数为-0.27和0.23。这说明,成膜剂LCM-8能满足埕海油田钻井要求,实现钻井过程中的储层保护。
- 钻井液 /
- 成膜剂 /
- 防止地层损害 /
- 封堵 /
- 表皮系数 /
- 埕海油田
Abstract: In order to reduce the reservoir damage caused by foreign fluid during drilling in Chenghai Oilfield,a new film-forming agent LCM-8 had been developed using styrene,butyl acrylate monomer and trigger ammonium persulfate,by emulsion polymerization method based on the film-forming technology.Laboratory tests showed that rheological properties of the drilling fluid could be gotten to carry cuttings after adding LCM-8,which could form a plugging area with low permeability at the polluted end of the core.The plugging rate and flowback permeability recovery rate could be higher than 90%.LCM-8 had been applied in two wells in Chenghai Oilfield,the results showed that the drilling fluid for the upper well section could meet the drilling demand after adding the film-forming agent,resulting in skin factors of -2.31 and -3.11 respectively,while the skin factors of two adjacent wells were -0.27 and 0.23 respectively without adding the film forming agent.It showed that LCM-8 could meet the demand of drilling and reservoir protection in Chenghai Oilfield.
- Drilling fluid /
- film-forming agent /
- prevent formation damage /
- plugging /
- skin factor /
- Chenghai Oilfield

HTML全文

参考文献(14)

[1]	张凤英,鄢捷年,周劲辉,等.苏丹六区低伤害防塌钻井液技术[J].石油钻探技术,2010,38(4):43-46. Zhang Fengying,Yan Jienian,Zhou Jinhui,et al.An anti-sloughing and low-damage drilling fluid used in Block 6,Sudan[J].Petroleum Drilling Techniques,2010,38(4):43-46.
[2]	李怀科,鄢捷年,叶艳,等.保护裂缝性气藏的超低渗透钻井液体系[J].石油钻探技术,2008,36(4):34-36. Li Huaike,Yan Jienian,Ye Yan,et al.Ultra low filtration drilling fluid for protecting fractured reservoirs[J].Petroleum Drilling Techniques,2008,36(4):34-36.
[3]	鄢捷年,赵胜英,王兆霏,等.理想充填油气层保护技术在青海油田深探井中的应用[J].石油钻探技术,2007,35(4):53-55. Yan Jienian,Zhao Shengying,Wang Zhaolin,et al.Application of formation damage control technology based on ideal packing theory to deep exploration wells in Qinghai Oilfield[J].Petroleum Drilling Techniques,2007,35(4):53-55.
[4]	徐同台,沙东,王伟,等.埕海油田2区沙河街组地层井壁失稳原因及对策[J].石油钻探技术,2010,38(3):49-53. Xu Tongtai,Sha Dong,Wang Wei,et al.Reasons of borehole instability in Block 2 of Chenghai Oilfeild and its measutres[J].Petroleum Drilling Techniques,2010,38(3):49-53.
[5]	李公让,蓝强,张敬辉,等.低渗透储层水平井伤害机理及保护技术[J].石油钻探技术,2010,38(06):60-64. Li Gongrang,Lan Qiang,Zhang Jinghui,et al.Low permeability reservoir horizontal formation damage and formation protection[J].Petroleum Drilling Techniques,2010,38(6):60-64.
[6]	王富华,邱正松,冯京海,等."超广谱"屏蔽暂堵钻井完井液新技术室内研究[J].石油钻探技术,2001,29(5):39-42. Wang Fuhua,Qiu Zhengsong,Feng Jinghai,et al.Lab study on the new technology of superior shielding and temporary plugging drilling-in fluids[J].Petroleum Drilling Techniques,2001,29(5):39-42.
[7]	罗春芝,曾繁涤,向兴金,等.钻井液及其处理剂抑制性评价方法的室内研究[J].石油钻探技术,2000,28(1):35-36. Luo Chunzhi,Zeng Fandi,Xiang Xingjin,et al.Lab research on evaluation method for inhibition of drilling fluids and treatment agents[J].Petroleum Drilling Techniques,2000,28(1):35-36.
[8]	胡玉国,袁继存.油井堵漏材料的应用[J].钻井液与完井液,2000,17(3):38-40. Hu Yuguo,Yuan Jicun.Application of plugging materials for lost circulation in petroleum drilling[J].Drilling Fluid Completion Fluid,2000,17(3):38-40.
[9]	袁春,孙金生,王平全,等.抗高温成膜降滤失剂CMJ-1的研制及其性能[J].石油钻探技术,2004,32(2):30-32. Yuan Chun,Sun Jinsheng,Wang Pingquan,et al.Development of CMJ-1:a high temperature film-forming fluid loss additive and the properties[J].Petroleum Drilling Techniques,2004,32(2):30-32.
[10]	白小东,蒲晓林.水基钻井液成膜技术的研究进展[J].天然气工业,2006,26(8):75-77. Bai Xiaodong,Pu Xiaolin.Evolution of membrane forming technology of water-based mud[J].Natural Gas Industry,2006,26(8):75-77.
[11]	苏俊霖,蒲晓林,任茂,等.抗高温无机/有机复合纳米降滤失剂室内研究[J].断块油气田,2012,19(5):626-628. Su Junlin,Pu Xiaolin,Ren Mao,et al.Research on inorganic/organic composite-nano fluid loss additive resistant to high temperature[J].Fault-Block Oil Gas Field,2012,19(5):626-628.
[12]	李海涛,赵修太,龙秋莲,等.镶嵌剂与成膜剂协同增效保护储层钻井液室内研究[J].石油钻探技术,2012,40(4):65-71. Li Haitao,Zhao Xiutai,Long Qiulian,et al.Laboratory study on drilling fluid of mosaic agent-membrane agent synergistic interaction for reservoir protection[J].Petroleum Drilling Techniques,2012,40(4):65-71.
[13]	孙金声,张希文.钻井液技术的现状、挑战、需求与发展趋势[J].钻井液与完井液,2011,28(6):67-76. Sun Jinsheng,Zhang Xiwen.Situations,challenges,demands and trends of drilling fluid technology[J].Drilling Fluid Completion Fluid,2011,28(6):67-76.
[14]	朱宽亮,卢淑芹,邢韦亮,等.南堡 1-3 人工岛钻井液技术[J].石油钻探技术,2010,38(3):54-58. Zhu Kuanliang,Lu Shuqin,Xing Weiliang,et al.Drilling fluid system used in Nanpu1-3 artificial island[J].Petroleum Drilling Techniques,2010,38(3):54-58.
