克拉苏构造带博孜1区块复杂超深井钻井完井关键技术

殷召海 李国强 王海 丁永亮 王雲 刘长柱

殷召海, 李国强, 王海, 丁永亮, 王雲, 刘长柱. 克拉苏构造带博孜1区块复杂超深井钻井完井关键技术[J]. 石油钻探技术, 2021, 49(1): 16-21. doi: 10.11911/syztjs.2020130
引用本文: 殷召海, 李国强, 王海, 丁永亮, 王雲, 刘长柱. 克拉苏构造带博孜1区块复杂超深井钻井完井关键技术[J]. 石油钻探技术, 2021, 49(1): 16-21. doi: 10.11911/syztjs.2020130
YIN Zhaohai, LI Guoqiang, WANG Hai, DING Yongliang, WANG Yun, LIU Changzhu. Key Technologies for Drilling and Completing Ultra-deep Wells in the Bozi 1 Block of Kelasu Structure[J]. Petroleum Drilling Techniques, 2021, 49(1): 16-21. doi: 10.11911/syztjs.2020130
Citation: YIN Zhaohai, LI Guoqiang, WANG Hai, DING Yongliang, WANG Yun, LIU Changzhu. Key Technologies for Drilling and Completing Ultra-deep Wells in the Bozi 1 Block of Kelasu Structure[J]. Petroleum Drilling Techniques, 2021, 49(1): 16-21. doi: 10.11911/syztjs.2020130

克拉苏构造带博孜1区块复杂超深井钻井完井关键技术

doi: 10.11911/syztjs.2020130
基金项目: 中国石油集团公司重大科技专项 “重大工程关键技术装备研究与应用”(编号:2018E-21)资助
详细信息
    作者简介:

    殷召海(1982—),男,江苏泗洪人,2007年毕业于中国石油大学(北京)电子信息工程专业,工程师,主要从事钻井井眼轨迹控制与提速技术研究。E-mail:yinzhaohai@163.com。

  • 中图分类号: TE245

Key Technologies for Drilling and Completing Ultra-deep Wells in the Bozi 1 Block of Kelasu Structure

  • 摘要: 克拉苏构造带博孜1区块复杂超深井钻井完井存在上部巨厚砾岩层钻速低、钻井周期长、固井质量差、钻井安全风险高等技术难点。为解决这些技术难点,结合区域地质特征,通过理论分析优化了井身结构,优选了系列钻井提速技术、提出了组合式盐底卡层技术,制定了一系列防漏堵漏技术措施和固井技术措施,形成了克拉苏构造博孜1区块超深井钻井完井关键技术。该技术在B1103井等4口井进行了现场试验,与未应用该技术的邻井相比,机械钻速提高了34.4%,钻井周期缩短了131 d,完井周期缩短了141 d,取得了良好的提速效果。这表明,该技术能够解决博孜1区块超深井钻井完井存在的技术难点,满足博孜1区块安全高效钻井完井的需求,可以在该区块推广应用。



  • 图 1  非平面切削齿的结构

    Figure 1.  Non-planar cutter structure

    图 2  B1103井的井身结构

    Figure 2.  Casing program of Well B1103

    表  1  钻井参数优化结果

    Table  1.   Optimization results of drilling parameters

    开次 优化
    前后
    泵压/
    MPa
    排量/
    (L·s–1
    钻压/
    kN
    转速/
    (r·min–1
    二开 优化前 20~24 40~50 60~120 60~85
    优化后 25~30 47~77 100~180 80~100
    三开 优化前 20~26 35~45 80~140 60~90
    优化后 25~30 39~56 120~200 80~110
    下载: 导出CSV

    表  2  应用新技术后的钻井完井指标统计结果

    Table  2.   Statistical results of drilling and completion indexes after application of the new technologies

    井号 井深/m 钻井周期/
    d
    完井周期/
    d
    平均机械钻速/
    (m·h–1
    B1-2 7 098 365 385 1.92
    B1T 6 998 359 385 2.03
    B1103 7 242 345 368 2.25
    B1104 7 299 355 378 2.12
    平均 7 159 356 379 2.07
    下载: 导出CSV
  • 狄勤丰,王春生,李宁,等. 巨厚砾岩层气体钻井井眼特征[J]. 石油学报,2015,36(3):372–377. doi: 10.7623/syxb201503013

    DI Qingfeng, WANG Chunsheng, LI Ning, et al. Wellbore characteristic of gas drilling in thicker conglomerate[J]. Acta Petrolei Sinica, 2015, 36(3): 372–377. doi: 10.7623/syxb201503013
    田军,杨海军,吴超,等. 博孜9井的发现与塔里木盆地超深层天然气勘探潜力[J]. 天然气工业,2020,40(1):11–19. doi: 10.3787/j.issn.1000-0976.2020.01.002

    TIAN Jun, YANG Haijun, WU Chao, et al. Discovery of Well Bozi 9 and ultra-deep natural gas exploration potential in the Kelasu tectonic zone of the Tarim Basin[J]. Natural Gas Industry, 2020, 40(1): 11–19. doi: 10.3787/j.issn.1000-0976.2020.01.002
    滕学清,崔龙连,李宁,等. 库车山前超深井储层钻井提速技术研究与应用[J]. 石油机械,2017,45(12):1–6.

    TENG Xueqing, CUI Longlian, LI Ning, et al. Research and application of ROP enhancement technology for in Kuqa foreland ultra-deep reservoir drilling[J]. China Petroleum Machinery, 2017, 45(12): 1–6.
    尹达,刘锋报,康毅力,等. 库车山前盐膏层钻井液漏失成因类型判定[J]. 钻采工艺,2019,42(5):121–123. doi: 10.3969/J.ISSN.1006-768X.2019.05.37

    YIN Da, LIU Fengbao, KANG Yili, et al. Types of lost circulation cause in salt-gypsum bed in Kuqa piedmont structure[J]. Drilling & Production Technology, 2019, 42(5): 121–123. doi: 10.3969/J.ISSN.1006-768X.2019.05.37
    王建华,闫丽丽,谢盛,等. 塔里木油田库车山前高压盐水层油基钻井液技术[J]. 石油钻探技术,2020,48(2):29–33. doi: 10.11911/syztjs.2020007

    WANG Jianhua, YAN Lili, XIE Sheng, et al. Oil-based drilling fluid technology for high pressure brine layer in Kuqa piedmont of the Tarim Oilfield[J]. Petroleum Drilling Techniques, 2020, 48(2): 29–33. doi: 10.11911/syztjs.2020007
    王建龙,齐昌利,柳鹤,等. 沧东凹陷致密油气藏水平井钻井关键技术[J]. 石油钻探技术,2019,47(5):11–16.

    WANG Jianlong, QI Changli, LIU He, et al. Key technologies for drilling horizontal wells in tight oil and gas reservoirs in the Cangdong Sag[J]. Petroleum Drilling Techniques, 2019, 47(5): 11–16.
    沙林秀. 钻井参数优化技术的研究现状与发展趋势[J]. 石油机械,2016,44(2):29–33.

    SHA Linxiu. Drilling parameters optimization technology status and development trend[J]. China Petroleum Machinery, 2016, 44(2): 29–33.
    伍葳,吴坷,文春宇,等. 长宁页岩气井水平段钻井参数强化对比评价[J]. 非常规油气,2019,6(5):80–84. doi: 10.3969/j.issn.2095-8471.2019.05.013

    WU Wei, WU Ke, WEN Chunyu, et al. The comparison analysis of drilling parameter optimizing practice in the horizontal section of two specific shale gas wells in Changning Area[J]. Unconventional Oil & Gas, 2019, 6(5): 80–84. doi: 10.3969/j.issn.2095-8471.2019.05.013
    李超,寇明富,王世永,等. 酒西地区白垩系地层新型PDC钻头技术及应用[J]. 石油机械,2019,47(3):7–13.

    LI Chao, KOU Mingfu, WANG Shiyong, et al. Application of new type of PDC bit for Cretaceous Formation in Jiuxi Region[J]. China Petroleum Machinery, 2019, 47(3): 7–13.
    彭齐,周英操,周波,等. 凸脊型非平面齿PDC 钻头的研制与现场试验[J]. 石油钻探技术,2020,48(2):49–55. doi: 10.11911/syztjs.2020035

    PENG Qi, ZHOU Yingcao, ZHOU Bo, et al. Development and field test of a non-planar cutter PDC bit with convex ridges[J]. Petroleum Drilling Techniques, 2020, 48(2): 49–55. doi: 10.11911/syztjs.2020035
    王树超,王维韬,雨松. 塔里木山前井涡轮配合孕镶金刚石钻头钻井提速技术[J]. 石油钻采工艺,2016,38(2):156–159.

    WANG Shuchao, WANG Weitao, YU Song. Combination of turbodrill and impregnated diamond bit to enhance ROP in drilling of wells in piedmont zone, Tarim Basin[J]. Oil Drilling & Production Technology, 2016, 38(2): 156–159.
    祝学飞,孙俊,舒义勇,等. ZQ2井盐膏层高密度欠饱和盐水聚磺钻井液技术[J]. 钻井液与完井液,2019,36(6):716–720.

    ZHU Xuefei, SUN Jun, SHU Yiyong, et al. A high density undersaturated saltwater drilling fluid for salt and gypsum drilling in Well ZQ2[J]. Drilling Fluid & Completion Fluid, 2019, 36(6): 716–720.
    周健,刘永旺,贾红军,等. 库车山前巨厚盐膏层提速技术探索与应用[J]. 钻采工艺,2017,40(1):21–24. doi: 10.3969/J.ISSN.1006-768X.2017.01.06

    ZHOU Jian, LIU Yongwang, JIA Hongjun, et al. Study to improve ROP in thick salt-gypsum layers at Kuqa piedmont area[J]. Drilling & Production Technology, 2017, 40(1): 21–24. doi: 10.3969/J.ISSN.1006-768X.2017.01.06
    周健,贾红军,刘永旺,等. 库车山前超深超高压盐水层安全钻井技术探索[J]. 钻井液与完井液,2017,34(1):54–59. doi: 10.3969/j.issn.1001-5620.2017.01.010

    ZHOU Jian, JIA Hongjun, LIU Yongwang, et al. Research on safe drilling technology for ultra deep ultrahigh pressure saltwater zones in piedmont area, Kuche[J]. Drilling Fluid & Completion Fluid, 2017, 34(1): 54–59. doi: 10.3969/j.issn.1001-5620.2017.01.010
    黄伟,王晓亮,杨晓榕,等. 一种适于盐膏层大井眼固井的抗盐高强水泥浆:以巴西Libra油田为例[J]. 长江大学学报(自然科学版),2020,17(5):42–48.

    HUANG Wei, WANG Xiaoliang, YANG Xiaorong, et al. A kind of salt-resistant and high-strength cement slurry suitable for large hole cementing in salt bed: taking the Libra Oilfield in Brazil as an example[J]. Journal of Yangtze University(Natural Science Edition), 2020, 17(5): 42–48.
    何选蓬,程天辉,周健,等. 秋里塔格构造带风险探井中秋1井安全钻井关键技术[J]. 石油钻采工艺,2019,41(1):1–7.

    HE Xuanpeng, CHENG Tianhui, ZHOU Jian, et al. Key technologies of safe drilling in Zhongqiu 1 Well, a risk exploration well in Qiulitag Tectonic Belt[J]. Oil Drilling & Production Technology, 2019, 41(1): 1–7.
    李早元,支亚靓,邓智中,等. 库车山前井防漏固井方法技术研究[J]. 钻井液与完井液,2015,32(1):55–58.

    LI Zaoyuan, ZHI Yaliang, DENG Zhizhong, et al. Technology for lost circulation control during well cementing in piedmont wells[J]. Drilling Fluid & Completion Fluid, 2015, 32(1): 55–58.
    杨川,刘忠飞,肖勇,等. 库车山前构造高温高压储层环空密封固井技术[J]. 断块油气田,2019,26(2):264–268.

    YANG Chuan, LIU Zhongfei, XIAO Yong, et al. Cementing technology of annulus sealing in high-temperature and high-pressure reservoir of Kuqa piedmont[J]. Fault-Block Oil & Gas Field, 2019, 26(2): 264–268.
    唐诚,王志战,陈明,等. 基于X射线荧光元素录井的深层页岩气精准地质导向技术[J]. 石油钻探技术,2019,47(6):103–110.

    TANG Cheng, WANG Zhizhan, CHEN Ming, et al. Accurate geosteering technology for deep shale gas based on XRF element mud logging[J]. Petroleum Drilling Techniques, 2019, 47(6): 103–110.
