低毒环保型油基钻井液体系室内研究

解宇宁

doi:10.11911/syztjs.201701008

低毒环保型油基钻井液体系室内研究

解宇宁

中国石油辽河油田分公司钻采工艺研究院, 辽宁盘锦 124010

详细信息

作者简介:
解宇宁(1987-),男,黑龙江安达人,2009年毕业于大庆石油学院石油工程专业,2012年获东北石油大学油气井工程专业硕士学位,工程师,主要从事井壁稳定、钻井液完井液体系开发和油气层保护等方面的研究。

中图分类号: TE254⁺.6
计量
- 文章访问数: 19787
- HTML全文浏览量: 103
- PDF下载量: 15198
出版历程
- 收稿日期: 2016-07-24
- 修回日期: 2016-10-18
- 刊出日期: 1899-12-31

Experimental Study on Low-Toxicity and Environment-Friendly Oil-Based Drilling Fluids

XIE Yuning

Drilling & Production Technology Research Institute, PetroChina Liaohe Oilfield Company, Panjin, Liaoning, 124010, China

摘要

摘要: 为了提高油基钻井液的环保性能，解决其生物毒性高、难于降解等问题，研制了低毒环保型油基钻井液。通过对普通原料油进行脱硫脱芳处理得到新型低毒油基钻井液用基础油，采用复合改性剂和新工艺处理有机土得到新型改性有机土，并对钻井液处理剂及加量进行优选，最终形成了低毒环保型油基钻井液体系。室内试验结果表明，该钻井液体系的高温高压滤失量为3.2~9.5 mL，沉降密度差最高0.06 g/cm3，破乳电压高达1 190 V以上，水侵和劣质土侵后乳化体系还可以保持稳定，二次岩屑回收率达到99.17%，线性膨胀率仅为1.92%，岩心渗透率恢复率达88.5%~94.6%。研究结果表明，低毒环保型油基钻井液体系的流变性、稳定性、抗污染性、润滑性、抑制性和储层保护性能良好，可满足复杂地层深井、超深井安全高效钻井的需求及环保要求。
- 油基钻井液 /
- 基础油 /
- 低毒环保 /
- 储层保护 /
- 改性有机土 /
- 钻井液性能 /
- 实验室试验
Abstract: To enhance the environmental protection performance of oil-based drilling fluids, and to eliminate problems related to the biological toxicity and difficulties in the degradation of conventional drilling fluids, an innovative low-toxicity and environment friendly oil-based drilling fluid has been developed. During its development, normal raw oil was primarily processed into base oil through desulfurization and dearomatization, then composed modifiers with innovative techniques were deployed to generate modified organic clay. Eventually, a low-toxicity oil-based drilling fluid system was generated through the optimization of additives and added specific volumes of such additives in the drilling fluid. Experimental results show that the innovative drilling system has filtration losses of 3.2-9.5 mL, a maximum differential precipitation density of 0.06 g/cm3 and ES over 1 190 V under high pressure and high pressure. In addition, the emulsion system can maintain desirable stability after water or low-quality clay invasion with a secondary cutting recovery rate of 99.17%, linear expansion rate of 1.92% and permeability recovery rate 88.5%-94.6%. Research results show that the newly developed low-toxicity and environmental-friendly oil-based drilling fluid system possesses outstanding rheological properties, stability, anti immersion, lubrication, inhibition and reservoir protection performances and can meet the requirements for safe and high-efficiency drilling and environmental protection in complex formations in the drilling of deep and ultra-deep wells.
- oil-based drilling fluid /
- base oil /
- low-toxicity environment friendly /
- reservoir protection /
- modified organic clay /
- performance of drilling fluid /
- experimental test

HTML全文

参考文献(18)

[1]	王中华.国内钻井液处理剂研发现状与发展趋势[J].石油钻探技术,2016,44(3):1-8. WANG Zhonghua.Present status and trends in research and development of drilling fluid additives in China[J].Petroleum Drilling Techniques,2016,44(3):1-8.
[2]	王茂功,徐显广,孙金声,等.气制油合成基钻井液关键处理剂研制与应用[J].钻井液与完井液,2016,33(3):30-34,40. WANG Maogong,XU Xianguang,SUN Jinsheng,et al.Study and application of additives for synthetic fluids with GTL as the base fluid[J].Drilling Fluid Completion Fluid,2016,33(3):30-34,40.
[3]	王旭东,郭保雨,陈二丁,等.油基钻井液用高性能乳化剂的研制与评价[J].钻井液与完井液,2014,31(6):1-4. WANG Xudong,GUO Baoyu,CHEN Erding,et al.Development and evaluation of a high performance oil base mud emulsifier[J].Drilling Fluid Completion Fluid,2014,31(6):1-4.
[4]	王显光,李雄,林永学.页岩水平井用高性能油基钻井液研究与应用[J].石油钻探技术,2013,41(2):17-22. WANG Xianguang,LI Xiong,LIN Yongxue.Research and application of high performance oil base drilling fluid for shale horizontal wells[J].Petroleum Drilling Techniques,2013,41(2):17-22.
[5]	林永学,王显光.中国石化页岩气油基钻井液技术进展与思考[J].石油钻探技术,2014,42(4):7-13. LIN Yongxue,WANG Xianguang.Development and reflection of oil-based drilling fluid technology for shale gas of Sinopec[J].Petroleum Drilling Techniques,2014,42(4):7-13.
[6]	林永学,王显光,李荣府.页岩气水平井低油水比油基钻井液研制及应用[J].石油钻探技术,2016,44(2):28-33. LIN Yongxue,WANG Xianguang,LI Rongfu.Development of oil-based drilling fluid with low oil-water ratio and its application to drilling horizontal shale gas wells[J].Petroleum Drilling Techniques,2016,44(2):28-33.
[7]	李雄,王显光,林永学,等.彭页2 HF井油基钻井液技术[J].钻采工艺,2015,38(1):40-43. LI Xiong,WANG Xianguang,LIN Yongxue,et al.Oil base drilling fluid technologies for Pengye 2 HF Well[J].Drilling Production Technology,2015,38(1):40-43.
[8]	张雪飞,张伟,徐新纽,等.准噶尔盆地南缘H101井高密度油基钻井液技术[J].石油钻探技术,2016,44(1):34-38. ZHANG Xuefei,ZHANG Wei,XU Xinniu,et al.High density oil-based drilling fluid deployed in Well H101 in the southern margin of the Junggar Basin[J].Petroleum Drilling Techniques,2016,44(1):34-38.
[9]	王中华.国内外油基钻井液研究与应用进展[J].断块油气田,2011,18(4):533-537. WANG Zhonghua.Research and application progress of oil-based drilling fluid at home and abroad[J].Fault-Block Oil Gas Field,2011,18(4):533-537.
[10]	侯业贵.低芳烃油基钻井液在页岩油气水平井中的应用[J].钻井液与完井液,2013,30(4):21-24. HOU Yegui.Application on low aromatic hydrocarbon oil based drilling fluid in shale oil and gas wells[J].Drilling Fluid Completion Fluid,2013,30(4):21-24.
[11]	张建阔,王旭东,郭保雨,等.油基钻井液用固体乳化剂的研制与评价[J].石油钻探技术,2016,44(4):58-64. ZHANG Jiankuo,WANG Xudong,GUO Baoyu,et al.Development and evaluation of a solid emulsifier for oil based drilling fluid[J].Petroleum Drilling Techniques,2016,44(4):58-64.
[12]	陶怀志,吴正良,贺海.国产油基钻井液CQ-WOM首次在页岩气威远H3-1井试验[J].钻采工艺,2014,37(5):87-90. TAO Huaizhi,WU Zhengliang,HE Hai.Tests of oil-base drilling fluid CQ-WOM made in China in Weiyuan H3-1 shale gas well[J].Drilling Production Technology,2014,37(5):87-90.
[13]	吴彬,王荐,舒福昌,等.油基钻井液在页岩油气水平井的研究与应用[J].石油天然气学报,2014,36(2):101-104. WU Bin,WANG Jian,SHU Fuchang,et al.Study and application of oil-based drilling fluids for horizontal well drilling[J].Journal of Oil and Gas Technology,2014,36(2):101-104.
[14]	刘明华,孙举,王中华,等.非常规油气藏水平井油基钻井液技术[J].钻井液与完井液,2013,30(2):1-5. LIU Minghua,SUN Ju,WANG Zhonghua,et al.Oil-based drilling fluid technology in horizontal wells with unconventional oil-gas reservoir[J].Drilling Fluid Completion Fluid,2013,30(2):1-5.
[15]	陈勉,葛洪魁,赵金洲,等.页岩油气高效开发的关键基础理论与挑战[J].石油钻探技术,2015,43(5):7-14. CHEN Mian,GE Hongkui,ZHAO Jinzhou,et al.The key fundamentals for the efficient exploitation of shale oil and gas and its related challenges[J].Petroleum Drilling Techniques,2015,43(5):7-14.
[16]	钱志伟,吴娇阳,李建成,等.全油基钻井液在油页岩地层钻井中的应用[J].大庆石油地质与开发,2016,35(1):170-174. QIAN Zhiwei,WU Jiaoyang,LI Jiancheng,et al.Application of the all oil-based drilling fluid in oil shale formation[J].Petroleum Geology Oilfield Development in Daqing,2016,35(1):170-174.
[17]	何振奎.泌页HF1井油基钻井液技术[J].石油钻探技术,2012,40(4):32-37. HE Zhenkui.Oil base drilling fluid technology applied in Well Biye HF 1[J].Petroleum Drilling Techniques,2012,40(4):32-37.
[18]	李建成,关键,王晓军,等.苏53区块全油基钻井液的研究与应用[J].石油钻探技术,2014,42(5):62-67. LI Jiancheng,GUAN Jian,WANG Xiaojun,et al.Research and application of oil-based drilling fluid technology in Block Su 53[J].Petroleum Drilling Techniques,2014,42(5):62-67.
