LQ乳液亲油水泥浆研究与性能评价

刘伟; 曾敏; 马开华; 陶谦

doi:10.11911/syztjs.201701007

LQ乳液亲油水泥浆研究与性能评价

doi: 10.11911/syztjs.201701007

刘伟^1,2,
曾敏^1,2,
马开华^1,2,
陶谦^1,2

1.
中国石化石油工程技术研究院, 北京 100101;
2.
页岩油气富集机理与有效开发国家重点实验室, 北京 100101

基金项目:

国家科技重大专项“彭水地区常压页岩气勘探开发示范工程”（编号：2016ZX05061）资助。

详细信息

作者简介:
刘伟(1965-),女,黑龙江宝清人,1990年毕业于石油大学(华东)钻井工程专业,2003年获石油大学(北京)油气井工程专业硕士学位,教授级高级工程师,主要从事固井水泥浆技术研究。

中图分类号: TE256⁺.6
计量
- 文章访问数: 19739
- HTML全文浏览量: 76
- PDF下载量: 15327
- 被引次数: 0
出版历程
- 收稿日期: 2016-04-25
- 修回日期: 2016-08-24
- 刊出日期: 1900-01-01

The Study and Property Evaluation of a Lipophilic Cement Slurry With LQ Emulsion

LIU Wei^1,2,
ZENG Min^1,2,
MA Kaihua^1,2,
TAO Qian^1,2

1.
Sinopec Research Institute of Petroleum Engineering, Beijing, 100101, China;
2.
State Key Laboratory of Shale Oil and Gas Enrichment Mechanisms and Effective Development, Beijing, 100101, China

摘要

摘要: 采用油基钻井液钻井时井壁和套管上附有油膜，造成固井时环空界面的胶结强度低。为解决该问题，从改善水泥浆自身的亲油性出发，选择羧酸类不饱和油溶性软单体和芳香族不饱和烯烃类刚性单体作为亲油单体，采用乳液聚合法将亲油单体与亲水单体聚合，合成了具有两亲结构的、稳定性较好的LQ乳液，并优选稳定剂，形成了LQ乳液亲油水泥浆。水泥浆性能评价试验结果表明：该水泥浆的API滤失量小于50 mL，稠化时间在150~300 min范围内可调、48 h抗压强度达到18 MPa以上，符合现场固井要求；LQ乳液在水泥石内部及表面形成疏水亲油膜，其与油膜接触时会吸油膨胀，从而提高附有油膜环空界面的胶结强度。研究表明，LQ乳液亲油水泥浆的性能达到现场固井要求，能提高附有油膜的环空界面的胶结强度。
- 固井 /
- 亲油水泥浆 /
- 乳液 /
- 水泥浆性能
Abstract: Wells drilled by using oil-based drilling fluids may have thin oil films attached to the sidewall and the casing, so low a cementation strength may be expected on annular interfaces during cementing. To solve this problem, the lipophilic properties of cement slurries have been modified through polymerization of lipophilic monomers and hydrophilic monomers through emulsion polymerization to generate LQ emulsion with desirable properties. During the process, soft carboxylic monomers dissolvable in unsaturated oil and rigid unsaturated olefin monomers were used as lipophilic monomers. By adding optimal stabilizers, lipophilic cement slurries with LQ emulsion were generated. Test results show that the slurry has an API filtration loss of no more than 50 ml, an adjustable thickening time of 150-300 min. and compressive strengths over 18 MPa in 48 hours. All these properties can meet the requirements of field cementation operations. LQ emulsion can form hydrophobic and lipophilic film inside and on surface of the cement. When in contact with oil film, the hydrophobic and lipophilic film may absorb oil then expand. In this way, the cementation strength in annular interface with oil film can be enhanced effectively. Test results show the lipophilic cement slurry prepared from LQ emulsion can be used in field cementation operations to enhance cementation strength of annular interfaces with oil films attached.
- cementing /
- lipophilic cement slurry /
- emulsion /
- performance of cement slurry

HTML全文

参考文献(21)

王显光,李雄,林永学.页岩水平井用高性能油基钻井液研究与应用[J].石油钻探技术,2013,41(2):17-22. WANG Xianguang,LI Xiong,LIN Yongxue.Research and application of high performance oil base drilling fluid for shale horizontal wells[J].Petroleum Drilling Techniques,2013,41(2):17-22.

张雪飞,张伟,徐新纽,等.准噶尔盆地南缘H101井高密度油基钻井液技术[J].石油钻探技术,2016,44(1):34-38. ZHANG Xuefei,ZHANG Wei,XU Xinniu,et al.High density oil-based drilling fluid deployed in Well H101 in the Southern Margin of the Junggar Basin[J].Petroleum Drilling Techniques,2016,44(1):34-38.

齐从丽,周成华.油基钻井液在百色油田的应用[J].断块油气田,2014,21(6):806-808. QI Congli,ZHOU Chenghua.Application of oil-based drilling fluid in Baise Oilfield[J].Fault-Block Oil Gas Field,2014,21(6):806-808.

何恕,李胜,王显光,等.高性能油基钻井液的研制及在彭页3HF井的应用[J].钻井液与完井液,2013,30(5):1-4. HE Shu,LI Sheng,WANG Xianguang,et al.Researh on high performance oil-based drilling fluid and it’s application on Well Pengye 3HF[J].Drilling Fluid Completion Fluid,2013,30(5):1-4.

罗立公,关增臣,苏常明,等.油基钻井液在特殊钻井中的应用[J].钻采工艺,1997,20(3):71-74. LUO Ligong,GUAN Zengchen,SU Changming,et al.Application of oil-based drilling fluid in the special drilling[J].Drilling Production Technology,1997,20(3):71-74.

何涛,李茂森,杨兰平,等.油基钻井液在威远地区页岩气水平井中的应用[J].钻井液与完井液,2012,29(3):1-5. HE Tao,LI Maosen,YANG Lanping,et al.Application of oil-based drilling fluid in shale gas horizontal well in district of Weiyuan[J].Drilling Fluid Completion Fluid,2012,29(3):1-5.

李建成,关键,王晓军,等.苏53区块全油基钻井液的研究与应用[J].石油钻探技术,2014,42(5):62-67. LI Jiancheng,GUAN Jian,WANG Xiaojun,et al.Research and application of oil-based drilling fluid technology in Block Su 53[J].Petroleum Drilling Techniques,2014,42(5):62-67.

高莉,张弘,蒋官澄,等.鄂尔多斯盆地延长组页岩气井壁稳定钻井液[J].断块油气田,2013,20(4):508-512. GAO Li,ZHANG Hong,JIANG Guancheng,et al.Drilling fluid for wellbore stability of shale gas in Yanchang Formation,Ordos Basin[J].Fault-Block Oil Gas Field,2013,20(4):508-512.

李建成,钱志伟,杜兴国,等.辽河油田油页岩地层全油基钻井液技术[J].钻井液与完井液,2015,32(4):9-12. LI Jiancheng,QIAN Zhiwei,DU Xingguo,et al.Whole oil base drilling fluid technology for oil shale drilling in Liaohe Oilfield[J].Drilling Fluid Completion Fluid,2015,32(4):9-12.

黄文红,李爱民,张新文,等.油基泥浆固井清洗液评价方法初探及性能研究[J].新疆石油天然气,2006,2(2):33-35. HUANG Wenhong,LI Aimin,ZHANG Xinwen,et al.A probe into an evaluation method of washing fluid of oil-based drilling fluid and its performance study[J].Xinjiang Oil Gas,2006,2(2):33-35.

刘伟,刘学鹏,陶谦.适合页岩气固井的洗油隔离液的研究与应用[J].特种油气藏,2014,21(6):119-122. LIU Wei,LIU Xuepeng,TAO Qian.Development and application of flushing spacer for cementing in shale gas reservoirs[J].Special Oil Gas Reservoirs,2014,21(6):119-122.

徐明,杨智光,肖海东,等.油包水钻井液耐高温冲洗液YJC-1的研究与应用[J].钻井液与完井液,2001,18(4):11-15. XU Ming,YANG Zhiguang,XIAO Haidong,et al.High temperature resisting flushing fluid YJC-1 tor oil based drilling fluid[J].Drilling Fluid Completion Fluid,2001,18(4):11-15.

RUEDA F,HEATHMAN J,SERRANO M.Hole cleaning and cement design for specific formation types[R].SPE 84560,2003.

齐静,李宝贵,张新文,等.适用于油基钻井液的高效前置液的研究与应用[J].钻井液与完井液,2008,25(3):49-51. QI Jing,LI Baogui,ZHANG Xinwen,et al.Applicable to efficient preflush oil-base drilling fluid in the research and application[J].Drilling Fluid Completion Fluid,2008,25(3):49-51.

王翀,谢飞燕,刘爱萍,等.油基钻井液用冲洗液BCS-020L研制及应用[J].石油钻采工艺,2013,35(6):36-39. WANG Chong,XIE Feiyan,LIU Aiping,et al.Research and application of flushing fluid BCS-020L for oil-based drilling fluid cleaning[J].Oil Drilling Production Technology,2013,35(6):36-39.

王志刚,李玉海,郭慧,等.生物驱油剂用于固井前置液的研究与应用[J].石油钻采工艺,2003,25(4):28-31. WANG Zhigang,LI Yuhai,GUO Hui,et al.Study and application of biological oil displacement agent in cementing pad fluid[J].Oil Drilling Production Technology,2003,25(4):28-31.

吴超,田荣剑,罗健生,等.油基钻井液润湿剂评价[J].西南石油大学学报(自然科学版),2012,34(3):139-144. WU Chao,TIAN Rongjian,LUO Jiansheng,et al.Evaluation the wettability of the wetting agent using in oil-base drilling fluid[J].Journal of Southwest Petroleum University(Science Technology Edition),2012,34(3):139-144.

王广雷,吴迪,姜增东,等.固井冲洗效率评价方法探讨[J].石油钻探技术,2011,39(2):77-80. WANG Guanglei,WU Di,JIANG Zengdong,et al.Discussion of evaluation method of cementing flushing efficiency[J].Petroleum Drilling Techniques,2011,39(2):77-80.

宋碧涛,姚晓,许仲梓.油基水泥浆水化程度及强度变化规律[J].南京工业大学学报(自然科学版),2004,26(4):1-4. SONG Bitao,YAO Xiao,XU Zhongzi.Study on hydration of oil based cement slurry and its strength development[J].Journal of Nanjing University of Technology(Natural Science Edition),2004,26(4):1-4.

宋碧涛,姚晓,许仲梓.提高油基水泥浆堵水材料封堵强度的研究[J].钻井液与完井液,2005,22(3):22-24,31. SONG Bitao,YAO Xiao,XU Zhongzi.Improving plugging performance of oil based slurry[J].Drilling Fluid Completion Fluid,2005,22(3):22-24,31.

余樟清,李伯耿,陈焕钦,等.聚合物乳液的稳定性[J].涂料工业,1998(11):41-44. YU Zhangqing,LI Bogeng,CHEN Huanqin,et al.Stability of polymer emulsion[J].Paint Coatings Industry,1998(11):41-44.
